DDJ-REV5
Scratch-style 2-channel performance DJ controller (black)
The DDJ-REV5 is a new-generation controller with Serato DJ Pro and rekordbox compatibility. This 2-channel unit offers an authentic scratch experience and innovative features including its large jogs, MAGVEL FADER, dedicated buttons for Stems control, the first-ever Auto BPM Transition, and Piano Play mode.
| Main Features | |
|
Compatible DJ Software
|
Serato DJ Pro |
| rekordbox | |
| Software System Requirements | Visit serato.com for its specifications. |
| Visit rekordbox.com for its specifications. | |
| Accessories | DDJ-REV5 |
| AC adaptor | |
| Power cord | |
| USB cable | |
| Warranty (for some regions) | |
| Quick Start Guide | |
| Precautions for use | |
| Serato DJ Pro Pitch ’n Time DJ voucher | |
|
Specifications
|
|
|
Width
|
736 mm |
| Depth | 377.2 mm |
| Height | 73.4 mm |
| Weight | 6.2 kg |
| Soundcard | 24 bit/48 kHz |
| Signal-to-Noise Ratio | 110 dB |
| Distortion | < 0.003 % (USB) |
| Power Consumption | DC 5 V, 3 000 mA |
| Frequency Range | 20 - 20000 Hz |
|
Performance Control
|
|
|
Channels
|
2 |
| Deck Control | 4 / Dual |
| Jog Wheel (Maximum Dimensions) | 206 mm |
| Sampler | 8slot x 4bank |
| Hot Cues | 8 |
| Pad Modes rekordbox | Hot Cue |
| Pad FX 1 | |
| Beat Jump | |
| Sampler | |
| Keyboard | |
| Piano Play | |
| Beat Loop | |
| Sample Scratch (rekordbox) | |
| Pad Modes Serato | Hot Cue |
| Roll | |
| Saved Loop | |
| Sampler | |
| Pitch Play | |
| Piano Play | |
| Stems | |
| Scratch Bank | |
| Saved Flip | |
| Slicer Loop | |
| Auto Loop/Auto Beat Loop | Yes |
|
Terminals
|
|
|
Inputs
|
2 MIC (XLR & 1/4 inch TRS Jack, 1/4 inch TRS Jack) |
| 1 AUX (RCA) | |
| Outputs | 2 MASTER (XLR, RCA) |
| 1 BOOTH (1/4 inch TRS Jack) | |
| 2 PHONES (1/4-inch stereo jack, 3.5-mm stereo mini-jack) | |
| USB | 3 USB Type-C ports (PC/Mac connection x 2, power supply x 1) |
